100k 4200 Power NTC Thermistor Epoxy Resin Negative Temperature Coefficient Sensor

Dongguan Ampfort Electronics Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 100k 4200 Power NTC Thermistor Epoxy Resin Negative Temperature Coefficient Sensor from wholesalers

    Buy cheap 100k 4200 Power NTC Thermistor Epoxy Resin Negative Temperature Coefficient Sensor from wholesalers
    • Buy cheap 100k 4200 Power NTC Thermistor Epoxy Resin Negative Temperature Coefficient Sensor from wholesalers
    • Buy cheap 100k 4200 Power NTC Thermistor Epoxy Resin Negative Temperature Coefficient Sensor from wholesalers
    • Buy cheap 100k 4200 Power NTC Thermistor Epoxy Resin Negative Temperature Coefficient Sensor from wholesalers
    • Buy cheap 100k 4200 Power NTC Thermistor Epoxy Resin Negative Temperature Coefficient Sensor from wholesalers

    100k 4200 Power NTC Thermistor Epoxy Resin Negative Temperature Coefficient Sensor

    Ask Lasest Price
    Brand Name : AMPFORT
    Model Number : NSAD0104FC-240CP
    Certification : UL
    Price : TBA
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 10,000,000 Pieces Per Month
    Delivery Time : 7-10 Workdays
    • Product Details
    • Company Profile

    100k 4200 Power NTC Thermistor Epoxy Resin Negative Temperature Coefficient Sensor


    Epoxy Resin NTC Thermistor 100K 4200 For Upscale Hotel Fire Alarm Dip Temperature Sensor


    I Features Of The Epoxy Resin NTC Thermistor 100K 4200


    * Highly responsive temperature sensor that has been dipped in epoxy resin

    * Temperature sensor designs according to device of fire alarm
    * Chip from Shibaura NTC thermistor
    * Epoxy-coated so it can resist humidity
    * Good coherence and stability, high humidity and durability
    * Enjoys a large sale in China, the US and Japan



    II Advantage Of The Epoxy Resin NTC Thermistor 100K 4200


    1. Novel structure, superior performance and high quality
    2. High sensitivity and fast response time
    3. Good sealing performance, strong adhesion, moisture-proof and anti-corrosion
    4. Large-scale production, high cost performance, high quality and low price


    III Dimensional Drawing Of The Epoxy Resin NTC Thermistor 100K 4200 (Unit:mm)


    NOMaterial NameItem/PN
    2-1.ElementR25=100KΩ±1% B25/50=4200K±1% DC
    2-2.CoatingResin (Black)
    2-3.Lead WireStents

    IV Electrical Performances Of The Epoxy Resin NTC Thermistor 100K 4200


    NOItemSignTest ConditionsMin.Normal valueMax.Unit
    4-1.Resistance at 25℃R25

    Ta=25±0.05℃

    PT≦0.1mw

    99.0100.0101.0
    4-2.B ValueB25/504158.042004242.0k
    4-3.Dissipation factorσTa=25±0.5℃≧0.9mW/℃
    4-4.Time constantτTa=25±0.5℃≦15sec
    4-5.Maximum rated powerP/≦25mW
    4-6.Operating temp.range//-40/+125

    V Thermistor application example Of The Epoxy Resin NTC Thermistor 100K 4200


    Thermistors serve a crucial role in temperature detection. For example, thermistor temperature detection

    can be used in fire alarms to detect fires based on a sudden change in temperature. Unlike photoelectric

    detectors or ionization alarms, thermistors only require heat to activate.


    1. Upscale hotel room
    2. Smart home products
    Temperature measurement for home electronics (fire alarm)


    VI Thermistor Temperature Detection in Fire Alarms


    The thermistor method, unlike the previous examples, uses heat detection to activate. The alarm activates

    once the thermistor detects a high temperature. Thermistor temperature detection doesn’t require smoke

    to activate and has fewer false alarms. The thermistor uses the ambient temperature of a building and

    will only activate when that temperature increases exponentially. The thermistor method is reliable in this

    fire alarm example as there would be few false alarms and a quicker alert rate, but the thermistor method

    is also versatile.


    VII Workshop Of The Epoxy Resin NTC Thermistor 100K 4200
